Base Frame：

1.The gantry is made of a 200mm x 150mm steel tube that has internal stiffeners. The gantries are welded, stressrelieved, and precision machined. The gantry has been engineered to provide a smooth, vibration free cut.;
2.The base frame is a one piece tubular steel frame that is welded, stress relieved, and machined. One piece construction allows for a very accurate and smooth cutting system. It also greatly reduces the amount of time need for installation and basically removes the possibility for installation errors that could effect the performance and accuracy of the system;
3.Fixed table and moving gantry design.

Dual Motor Drive：

Adopt dual motor drive( step motor or hybrid servo or servo motor), higher speed, more power.

Test each machine：

We are not only used to detect the linear accuracy, but also the geometric accuracy of the machine. So you can fully believe that the machine you purchased is accurate and has been calibrated correctly.

Linear Bearings

25 mm ball linear bearing profile rails form Taiwan or Germany.
High rigidity and top load capacities in all load directions.
Lowest possible noise level and best running characteristics.
High torque load capacity.

Z axis Ball Screw Assembly

The 16mm ball screw is supported by precision dual angular contact ball bearings in a steel housing.

Linear Auto Tool Changer

4-6 tool holders

Tool Calibrator

Automatic tool calibrator block.

Auto Calibrate tool sensor

Spindle

HSD fun cooling spindle from Italy.and with auto change tools function, 24000rpm, ISO30

Vacuum Table

4 areas vaccum table , controlled separate

Drag chain system

The whole closed chain system is adopted, can protect  the cable better.

Electrical components

Abb, Schneider, Wago and other imported brands are used for electrical components in the cabinet.

      Ezletter developed EZCNC Controller System with its own intellectualEzletter developed EZCNC Controller System with its own intellectualproperty right. We can provide customers with customizable products andservices. All the functions are integrated in the graphical keypad. The 30buttons can complete more than one hundred of functions.

      EZCNC Controller is a CPU+DSP+FPGA control system. The specialdigital processing chip combined with the optimization algorithm makes themachining precision and speed reach the leading level of the internationalsimilar products.

EZCNC Feature：

1) Easy to operate, graphical keypad.

2) Multi home set, 6 fast home and 3 permanent home with z axis coordinates

3) High Precision find limits, Capture home rapidly

4) Six jog mode. Step move and continues move, absolute move and relative by input value.

5) Park in the max position

6) Auto Surface

7) Max cut depth protection, by auto surface block or input value

8) Look ahead, unlimited for the size of job file，G-code inspection before machining

9) Feed override real-time，spindle speed adjustment real-time

10) Network DNC, USB disk，2GB hard disk inside

11) Can control four to eight axes

12) Spindle Warm-Up

13) Modbus communicate with inverter, real time display spindle power and torque

14) Linear tool changer, Carrousel tool changer, servo tool changer and multi-head spindle

15) ATC Collision Detection

16) Auto tool calibration, tool length compensation

17) Tangential knife

18) Dust tracker

19) Rigid tapping

20) Linear interpolation, circular interpolation, helical interpolation

21) Approximate restart and Breakpoint continues，Pause and move and resume，and surface canbe adjusted in the pause.

22) Electronic saw function: Line, rectangle and circle

23) High strength casting aluminum shell with good EMC

24) Integrated high brightness OLED screen and emergency stop on the Keypad

25) Get the center from two point , three points or four points

26) Gantry axis

27) Dry running mode, preview tool path

28) High speed double pulse output.

29) Laser set surface, Laser scan, Laser tracker
